ab CHF 14.90

💬 076 792 63 50 (WhatsApp / SMS)

Model parameters Product name: 810-B2/832-B2 Chip model: NRF51822/NRF52832/NRF52810 Communication distance: within 50m of practical distance (adjustable from 1m to 50m) Broadcast power: - 95dB-4dB (adjustable 1-9 gears) Broadcast interval: 1000ms/time (adjustable 80ms - 4000ms) Parameter configuration: configurable: UUID Major Minor Mac address Product name Working standby: 9 months/no sensor (can change the broadcast power, shorten the interval or extend the working time) Battery model: CR2032 (replaceable battery) Battery capacity: 240mAh Product size: module plate circle diameter 25.5mm shell diameter 32.6mm thickness 9mm Product features: IP67 waterproof and dust-proof (splash-proof/rain-proof/non-soaking) Default parameters UUID (device ID): "FDA50693 - A4E2-4FB1-AFCF-C6EB07647825" Note: The default UUID of WeChat shake Major: 1 Minor: 2 Measured power: - 59dBm, 0xC5 Note: the measured rssi value at a distance of 1 meter from the equipment Transmission Power:+0dBm Broadcasting Interval: 1000ms Bluetooth address (MAC): burned by the manufacturer, subject to the actual measured value IBeacon Name: name: RDL. 52810/name: RDL52832 Battery: new battery, subject to the actual measured value [Beacon Operating Instructions] ① Beacon can be used directly when it is powered on. Press and hold the button in the middle right above the beacon. Three flashes are for power on and one flash is for power off. Beacon parameter configuration software: [Apple] App Store Search: RL Beacon Tool software [Android] Use iBeacon software for Android *Please confirm that all APP permissions are open, and then open Bluetooth and location at the same time, and adjust the rssi value to the appropriate location *The default password of the software connection device is 123456 *The software needs to successfully enter the password within 15 seconds to connect the device, otherwise an error will occur, and you need to reconnect ④ [Common error]: No sign
