  Option: NoorWithDriver Board Version Options 2.15″  E-Paper (B) Low Power, Wide Viewing Angle, Paper-Like Effect Without Electricity Ideal for price tags, shelf labels, industrial instruments... Note: the driver board is optional, please refer to the Package Content for detailed part list Advantages Of EINK E-paper display utilizes microcapsule electrophoretic technology for displaying, the principle is: charged particles suspended in clear fluid will move to sides of microcapsule when electric field is applied, making the microcapsule become visible by reflecting ambient light, just as traditional printed paper. E-paper display will clearly display images/texts under lamplight or natural light, requires no backlight, and features nearly up to 180° viewing angle. It is usually used as e-reader due to its paper-like effect. Standard Raspberry Pi 40PIN GPIO Header Compatible With Raspberry Pi Series Boards, Jetson Nano, RDK X3 * for reference only, the Raspberry Pi in the picture is NOT included. Optional For E-Paper Driver Board Onboard SPI Control Interface, For Use With Controller Boards Like Raspberry Pi / Arduino / STM32 VCC Power (3.3V / 5V input) GND Ground DIN SPI MOSI pin CLK SPI SCK pin CS SPI chip selection, low active DC Data/Command selection (high for data, low for command) RST External reset, low active BUSY Busy status output pin Onboard Voltage Translator Compatible With 3.3V / 5V MCUs Application Examples Suitable For Price Tags, Asset/Equipment Tags, Shelf Labels, Conference Name Tags... Outline Dimensions 2.15inch e-Paper (B) 2.15inch e-Paper HAT+ (B) Package Contains
