1 Meter 220V 5~48V 12V Heizelement Elektrisches Rohrheizband DIY Heizmatte, LKW-Sitzheizung Heizdraht für den Winter
5V 12V 24V Low Volt Nickel-chromium Alloy Heating Wire Cable Electrique Electric DIY Kit Heating Blanket May Wire Description: Product Name: silicone rubber hotline Notice: the price is for 1 meter cable. Heating Material: Nickel-chromium alloy or a copper-nickel alloy Power frequency withstand voltage: 2000 V Insulation resistance: ≥100MΩ Max enduring temperature: 200C Withstand voltage: 300 V Diameter: 2 mm Product life: more than 30000 hours Resistance: 0.3; 0.6; 1; 2; 3; 5; 7; 10; 15; 20; 25; 30; 38; 50; 60; 74; 90; 120; 180; 256; 362; 588 Ohm/m (we have many different types of resistance type for you to choose, if cannot choose, please contact us or write an order note when make the order.) Power caculation: P=(U*U)/(L*R) U is voltage, L is the length of heating wire, R is resistance per meter. For example: If we use 5 meters 0.6 Ohm/m heating wire on 12V, the power consumption = (12*12)/(5*0.6)=48 watts. 48w/5m=9.6w/m Question: What is the power of the cable? And what is heating temperature? Answer: 1. The power of the cable is based on the length that you use, you can calculate the power according to above examples. 2. Power = 5W/m, the temperature is about 30~40C degrees; Power = 10W/m, the temperature is about 40~50C degrees; Power = 15W/m, the temperature is about 50~60C degrees; Power = 20W/m, the temperature is about 60~70C degrees; Please notice that this is for your reference, not exactly right because of different test conditions. If you don't know which resistance to choose, please contact us and provide the information of your application: 1. The working voltage. 2. The heating temperature that you want to heat up. 3. The length of using per piece.
