CHF 12.90

💬 076 792 63 50 (WhatsApp / SMS)

5A MPPT Solar Panel Regulator Controller Solar Charge Controller Battery Charging Module 9V 12V 18V 24V 300KHz PWM Auto Switch Input and output terminals are made of high-end switching power supply for high-frequency low-impedance electrolytic capacitors (LOW ESR), ensure that the output ripple. Can effectively filter out the switching power supply glitches. Module parameters : The modular nature: a real MPPT solar maximum power point tracking, automatic intelligent charge management, low power consumption Input voltage: DC 8-28V input DC voltage. (Prohibition AC input) Output voltage: DC 5-26V stepless transmission For lower output voltage, please contact the owner. 6V battery can be charged either 12 or 8.4V, 12.6V, 16.8V lithium battery 7.2V, 10.8V, 14.4V lithium iron phosphate battery 2-4 string lithium batteries, lithium iron phosphate charge management board Output Current: 2A / 5A maximum charging current in two: A version 5A B version of A 2A 5A default shipping version Charge indicator: Yes. Fast charging red light long bright red and blue lights flash alternately charged. Full automatic stop. MPPT function: a. MPPT maximum power point automatic tracking, to maximize the full use of solar charging Low pressure: 1V (as is the step-down voltage regulator, the input voltage is at least higher than the output 1V) Low power consumption: Yes! Ultra-low pressure designed to achieve low power consumption and high efficiency, professional adaptation of solar panels Operating temperature: Industrial grade (-40 ° to + 85 °) Load regulation: ± 1% Voltage regulation: ± 0.5% Conversion efficiency: Max: 93% Peak: 95% for different lighting conditions vary. Charging: automatic intelligent three-stage charging mode. Self-tracking solar power charge current automatically adjust the size No-load current: 3MA even weak morning sunlight can easily start automatically, eliminating manual switch. nput reverse polarity protection: Yes. Exclusively designed
