NRF24L01+PA+LNA Wireless Transceiver RF Transceiver Modul 2,4G 1100m mit Antenne und NRF24L01+ Breakout Adapter mit 3,3V (5 Stück)
NRF24L01+ 2.4G wireless data transmission module 2.4GHz NRF24L01 upgrade version NRF24L01+PA+LNA 1000 Meters For Arduino Description: If you want to set up your wireless communication system with low cost, this wireless Transceiver module is the most suitable module to choose! It can achieve a good balance between wireless transition performance and cost! You can easily add it with your own MCU/ARM/PIC/AVR/STM32 system! What's more, this NRF24L01+ module is designed with Power amplifier and SMA antenna This allowed you to use the wireless communication up to 800+ meters! (No barrier) Specifications: Range: 800+ meters line of sight Frequence: 2.4GHz~2.5GHz Operating voltage: 3 ~ 3.6V Max Max Current: 115mA Multi-frequency: 125 frequency A host microcontroller can communicate and configure the nRF24L01+ over a 4-pin Serial Peripheral Interface (SPI). The configuration registers are accessible through the SPI connection. Configurable parameters include frequency channel (125 selectable channels), output power, and data rate (data rates: 250kbps, 1Mbps, and 2Mbps). The on chip voltage regulator accepts supply voltages from 1.9 to 3.6V. The module has 5V tolerant inputs which allows for direct connection of SPI pins to the ( compatible with ) ArduinoIDE. Internal filtering results in high margins of meeting RF regulatory standards. The module's radio uses Gaussian Frequency-Shift Keying (GFSK) modulation as well as fast Automatic Gain Control (AGC). The module includes an Interrupt Request (IRQ) pin which can be used to wake the host microcontroller, (ex: for ArduinoIDE), from sleep when the module receives a transmission providing great power conservation in battery devices. Package Included:（according your choice) 1/3/5 x Wireless Module 1/3/5/ x Antenna 1/3/5/ x SOCKET
